Case Report - Imaging in Medicine (2018) Volume 10, Issue 1
Tumor syndrome, hepatic and hematological features revealing undiagnosed early rheumatoid arthritisZeineb Alaya1, Mouna Braham1, Imen Akkari2, Senda Majdoub3, Badreddine Sriha4, Elhem Ben Jazia2, Dajla Abbassi Bakir3, Elyes Bouajina1
2Department of Gastroenterology, Farhat Hached Hospital, Sousse, Tunisia.
3Department of Radiology, Farhat Hached Hospital, Faculty of Medicine of Sousse, Sousse, Tunisiaa
- *Corresponding Author:
- Zeineb Alaya
Department of Rheumatology
Farhat Hached Hospital, Faculty of Medicine of Sousse
E-mail: [email protected]
Background: Extra-articular manifestations in rheumatoid arthritis (RA) are rare and generally occur in an advanced stage of the disease. We report a case of an unusual onset of early RA.
Case presentation: A 21 year old male complains of polyathritis involving small and large joints, associated with fever, asthenia, anorexia and weight loss. The temperature was up to 38.8°. There was a left cervical adenopathies, hepato-splenomegaly and there were synovitis in all joints sparing distal interphalangial joints. The erythrocyte sedimentation rate was accelerated; the C-reactive protein was up to 222 mg/l. The number of white blood cells were 9000/mm3 with monocytosis, lymphocytosis and thrombocytosis at 986000/mm3 . There was cholestasis with cytolysis. Rheumatoid factor (RF) and anti-cyclic citrullinated peptide antibodies (ACCP) were positive. The hands X-ray didn’t show any RA specific signs. The chest X-Ray showed a left pleurisy. The CT scan showed multiple axillar and mediastinal lymphadenopathies, hepato-splenomegaly with multiple coelio-mesenteric and retroperitoneal lymph nodes. The pleural biopsy as well as the biopsy of the adenopathy and the salivary glands didn’t show any specific abnormalities or signs of lymphoma. The hepatic biopsy revealed an inflammatory lymphohistiocytic infiltrate with rare foci of necrosis and a dilatation of the hepatic sinusoids. The diagnosis of RA was suspected and confirmed by the MRI of the hands.
Conclusion: RA may have an unusual onset such as hematologic, hepatic, pleuropulmonary features or tumor syndrome, but it is rarely reported. The diagnosis in this case is difficult
rheumatoid arthritis; fever; lymphadenopathy; hepatomegaly; hepatic biopsy; pleurisy
Rheumatoid arthritis (RA) is a chronic autoimmune inflammatory disease, characterized by a severe joint involvement . It can involve other organs and tissues as well as synovial joints . Extra-articular manifestations are all systemic features which are indirectly related to the locomotors system , and there is no clear classification for these manifestations . In RA, extra-articular manifestations are present in about 40% of cases in the course of their disease  and generally occur in an advanced stage of the disease . But in rare cases, they can be present in early RA [5,6]. These events can affect both sexes and can occur at any age . Patients with high levels of rheumatoid factor (RF), are more exposed to develop extra-articular manifestations in the course of RA such as rheumatoid nodules, rheumatoid vasculitis and pleuropulmonary, cardiovascular, neurologic, digestive, cutaneous, hematologic and ocular complications [7-9]. The most frequently observed are rheumatoid nodules, osteoporosis, Gougerot’s syndrome, pleuropulmonary, hepatic and renal manifestations. We reported a case of an early diagnosed RA patient with very rare extraarticular manifestations: axillar, mediastinal and intra-abdominal lymphadenopathies and hepatosplenomegaly, with hematological features.
A 21 year old male who was referred to our department for exploration of polyathritis since one month, involving small and large joints (all joints except the distal inter-phalangeal joints of hands), in a context of high fever, asthenia, anorexia and weight loss. On physical examination, the temperature was up to 38.8°, there was a left cervical adenopathies, hepatosplenomegaly and there were synovitis in all joints sparing distal inter-phalangeal joints. The erythrocyte sedimentation rate was accelerated; the C-reactive protein was up to 222 mg/l. The number of white blood cells were 9000/mm3 with monocytosis, lymphocytosis and thrombocytosis at 986000/mm3. The hepatic biology showed a cholestasis (eight times the normal value) and a cytolysis (three times the normal value) (TABLE 1) with negative antibodies anti smooth muscle, anti LKM1 and anti-mitochondrial antibodies. Rheumatoid factor (RF) found by the Latex and Rose-Waller reaction (IgG, IgA, IgM) and anticyclic citrullinated peptide antibodies (ACCP) measured by ELISA were positive (160,110,330 and 719 UI/L, respectively). Anti-nuclear antibodies are negative. Infectious endocarditis was eliminated by normal cardiac ultra-sound and negative blood cultures. Wright serology and the card test were negative. Viral serology (hepatitis B and C) was negative, anti EBV was positive to IgM and IgG, anti CMV was positive to IgG and parvovirus serology was negative. Tuberculosis explorations were all negative. The hands X-Ray didn’t show any RA specific signs. The chest X-Ray showed a left pleurisy (FIGURE 1). The CT scan showed multiple axillar and mediastinal lymphadenopathies, hepato-splenomegaly (FIGURE 2) with multiple coelio-mesenteric and retroperitoneal lymph nodes (FIGURE 3). The pleural biopsy as well as the biopsy of the adenopathy and the salivary glands didn’t show any specific abnormalities or signs of lymphoma. The hepatic biopsy revealed an inflammatory lymphohistiocytic infiltrate with rare foci of necrosis and a dilatation of the hepatic sinusoids. After eliminating malignant haemopathy essentially lymphoma, connective tissue disease, chronic tuberculosis and viral infection, the diagnosis of RA was suspected. The MRI of the hands was practiced and showed evident synovitis of the fingers with bone edema of the phalanges (FIGURE 4). The patient was diagnosed with RA basing on ACR 1987/EULAR 2010, Rheumatoid Arthritis Classification Criteria [10,11] and was treated with corticosteroids at a dose of 1 mg/Kg. The evolution was marked by the absence of fever in two days, the regression of the inflammatory biological syndrome, the disappearance of cytolysis, the reduction of cholestasis and the improvement of synovitis. After six months, we obtained a normalization of the hematologic and liver balance (TABLE 1), the regression of the tumor syndrome and the disappearance of the pleurisy in the CT-scan. The hands X-Ray showed bilateral radio-carpian and intercarpian narrowing and two geodes in the fifth right metacapo-phalangian (FIGURE 5). The patient was treated with methotrexate at a dose of 15 mg/week, but, he still complaining with many synovitis and high disease activity. So, a biological treatment with anti-TNF alpha is recommended.
Figure 4: MRI of the hands showed synovitis at the 5th finger metacarpophalangeal and proximal interphalangeal sites at the 2.3 and 4th fingers. There was also a bone edema of all the proximal interphaplangiennes and the metacarpophalangeal of the 5thfinger. The tendons are of signal and morphology preserved.
|First biological results||3 months after||6 months after|
|White cells (elements/ml)||9000||17700||11300|
|C-Reactive protein (mg/L)||222.2||7.8||5.5|
|Gamma glutamyl transaminase (GGT) (U/L)||382.2||30.9||33|
|Alcalin Phosphatase (U/L)||92.5||27.6||24|
Table 1. Showed the evolution of biological findings.
Extra-articular manifestations in RA generally occur in advanced stage of the disease, contrarily of our patient whose many unusual features were present at the moment of RA diagnosis. He presented exceptional signs like the cervical, axillar and mediastinal lymphadenopathies, which suggested a lymphoma or other tumor. In fact, the bilateral mediastinal and hiliaire adenopathies have also been reported in RA. However, if there are peripheral adenopathies, palpable ones are found in 30% of RA cases. Intrathoracic lymphadenopathies, in particular mediastinal, have been very rarely described in the literature [12,13]. In the study of Remy- Jardin et al. , the thoracic CT revealed intrathoracic adenopathies in nine of 84 patients with RA. In a series of 46 patients, Despaux  found intrathoracic lymphadenopathy revealed by CT in 13 patients. Marilier et al.  reported the observation in of an elderly woman aged of 83 years with a rheumatoid pleurisy, pericardial effusion and mediastinal and axillary adenopathies. All these signs have been linked to rheumatoid arthritis, which was reinforced by the good evolution under specific treatment of RA. However, the discovery of mediastinal adenopathies in a patient with RA causes fear above all malignant cause justifying an exhaustive etiological investigation .
Concerning gastrointestinal complications in RA, in most cases, they are caused by mediations . Exceptionally, the affection of the gastrointestinal system can be caused by mesenteric vasculitis . Our patient presented an hepato-splenomegaly with multiple coeliomesenteric and retroperitoneal ganglia, which wasn’t reported in the literature. Hepatic manifestations in RA can be observed with hepatomegaly which is seen in 22% of patients by scintigraphic scanning and correlates with the elevation of RF [18,19]. Massive hepatomegaly can occur in juvenile RA, and is associated with fever and mild perturbation of liver function . Transaminases and bilirubin are usually normal in RA. But serum alkaline phosphatase (AP) is increased in 18-46% of cases and is correlated with the activity of RA in some studies . Gamma glutamyl transaminase (GGT) is elevated in 23-77% of patients and correlates with active disease. The liver histologic abnormalities were found in 92% of patients with RA in an autopsy study  and 65% in a clinical study . They are usually mild and can be correlated with the disease activity . The most frequent are congestion, periportal fibrosis, portal tract inflammation, fatty liver , sinusoidal dilatation , amyloid, and, rarely, cirrhosis .
Hematological manifestations in RA such as anemia, neutropenia, thrombocytopenia, thrombocytosis and eosinophilia, can occur either at the moment of diagnosis or during the disease course . Thrombocytosis is frequent in active RA and is correlated with the number of active inflamed joints .
Extra-articular manifestations in RA are serious and they should be aggressively treated and monitored . There aren’t specific treatments and generally they stabilize with optimized treatment of the RA.
Extra-articular manifestations in RA are dominated by cardiac, pulmonary, hepatic, ocular ones and Sjogren syndrome. Unusual features like tumor syndrome and hematological perturbations should be seriously considerate. In all cases, an exhaustive investigation is necessary to eliminate infectious or malignant causes.
The authors declare no competing interest.
- Lee JE, Kim IJ, Cho MS et al. A case of rheumatoid vasculitis involving hepatic artery in early rheumatoid arthritis. J. Korean. Med. Sci. 32, 1207-1210 (2017).
- Cojocaru M, Cojocaru IM, Silosi I et al. Extra-articular manifestations in rheumatoid arthritis. Maedic. 5, 286-91 (2010).
- Mielants H, Van DBF. Extra-articular manifestations. Clin. Exp. Rheumatol. 27, 56-61 (2009).
- Cimmino MA, Salvarani C, Macchioni P et al. Extra-articular manifestations in 587 Italian patients with rheumatoid arthritis. Rheumatol. Int. 19, 213-217 (2000).
- Turesson C, Jacobsson L, Bergstrom U. Extra-articular rheumatoid arthritis: prevalence and mortality. Rheumatology. 38, 668-674 (1999).
- Young A, Dixey J, Cox N et al. How does functional disability in early rheumatoid arthritis (RA) affect patients and their lives? Results of 5 years of follow-up in 732 patients from the early RA study (ERAS). Rheumatology. 39, 603-611 (2000).
- Gabriel SE, Crowson CS, Kremers HM et al. Survival in rheumatoid arthritis: a population-based analysis of trends over 40 years. Arthritis. Rheum. 48, 54-58 (2003).
- Turesson C, Fallon WM, Crowson CS et al. Extra-articular disease manifestations in rheumatoid arthritis: incidence trends and risk factors over 46 years. Ann. Rheum. Dis. 62, 722-727 (2003).
- Hochberg MC, Johnston SS, John AK. The incidence and prevalence of extra-articular and systemic manifestations in a cohort of newly-diagnosed patients with rheumatoid arthritis between 1999 and 2006. Curr. Med. Res. Opin. 24, 469-480 (2008).
- Arnett FC, Edworthy SM, Bloch DA et al. The American Rheumatism Association 1987 revised criteria for the classification of rheumatoid arthritis. Arthritis. Rheum. 31, 315-324 (1988).
- Radner H, Neogi T, Smolen JS et al. Performance of the 2010 ACR/EULAR classification criteria for rheumatoid arthritis: a systematic literature review. Ann. Rheum. Dis. 73, 114-123 (2014).
- Marilier S, Martin PI, Mazen E et al. Décompensation cardiorespiratoire au cours d’une polyarthrite rhumatoïde. La. Revue. De. Médecine. Interne. 30, 994-995 (2009).
- Martinez FJ, Karlinsky JB, Gale ME et al. Intrathoracic lymphadenopathy. A rare manifestation of rheumatoid pulmonary disease. Chest. 97, 1010-1012 (1990).
- Remy JM, Remy J, Cortet B et al. Lung changes in rheumatoid arthritis: CT findings. Radiology. 193, 375-382 (1994).
- Despaux J, Manzoni P, Toussirot E et al. Prospective study of the prevalence of bronchiectasis in rheumatoid arthritis using high-resolution computed tomography. Rev. Rhum. Engl. Ed. 65, 453-461 (1998).
- Khammassi N, Bayouth A, Abdelhedi H et al. Intrathoracic lymphadenopathy: an unusual manifestation of rheumatoid arthritis. Rev. Pneumol. Clin. 68, 54-57 (2012).
- Cronstein BN. Interleukin-6: A key mediator of systemic and local symptoms in rheumatoid arthritis. Bull. NYU. Hosp. Jt. Dis. 65, 11-15 (2007).
- Tiger LH, Gordon MH, Ehrlich GE et al. Liver enlargement demonstrated by scintigraphy in rheumatoid arthritis.J. Rheumatol. 3, 15-20 (1976).
- Ebert EC, Hagspiel KD. Gastrointestinal and hepatic manifestations of rheumatoid arthritis. Dig. Dis. Sci. 56, 295-302 (2011).
- Ruderman EM, Crawford JM, Maier A et al. Histologic liver abnormalities in an autopsy series of patients with rheumatoid arthritis. Br. J. Rheumatol. 36, 210-213 (1997).
- Rau R, Pfenninger K, Boni A. Liver function tests and liver biopsies in patients with rheumatoid arthritis. Ann. Rheum. Dis. 34, 198-199 (1975).
- Laffon A, Moreno A, Gutierrez BA et al.Hepatic sinusoidal dilatation in rheumatoid arthritis. J. Clin. Gastroenterol. 11, 653-657 (1989).
- Bowman SJ. Hematological manifestations of rheumatoid arthritis. Scand. J. Rheumatol. 31, 251-259 (2002).
- Ustun C, Kallab A, Loebl D et al. Rheumatoid arthritis and immune thrombocytopenia: a report of two cases. Clin. Rheumatol. 21, 543-544 (2002).
